What's on your bench?

Agent Smith

Hack of all trades
Local time
10:47 AM
User ID
5180
Joined
Jan 28, 2018
Messages
3,088
Reaction score
18,331
Location
Northeast ohio
Country flag
Aftermarket ms660 hyway crankshaft shenanigans. Something didn't seem right when side x side with the oem one. Sure enough the keyway is machined 10° retarded from oem. The magnets in the aftermarket flywheel are 7° retarded from oem so if i did all my maths and figuring right, timing is 17° retarded total from factory. Atleast I know where I'm at timing wise now and can adjust. When it's all together and running, I may make some marks and hook a timing light up to see where things are exactly . Does anyone know what the factory spec for timing at idle is on these 660's by chance? I have the 1314 coil if it matters.
S=stock
H=hyway

20230203_153903.jpg 20230203_153908.jpg 20230203_153601.jpg

Last edited:

GerbrandR

Super OPE Member
Local time
4:47 PM
User ID
17484
Joined
Jul 11, 2021
Messages
82
Reaction score
392
Location
The Netherlands <-> Austria
Country flag
Received my 28'' Stihl light bar today. And I wanted to try my 3d printed adapter. I did some light cuts and I didn't notice anything bad, so I assume it would be safe to use.
But still I want to have one out of metal.

20230207_154303.jpg 20230207_154804.jpg

The Stihl 28'' light bar is almost one pound lighter than the Husqvarna 28'' regular bar.


lehman live edge slab

Live Action
Local time
9:47 AM
User ID
3953
Joined
Sep 2, 2017
Messages
3,699
Reaction score
12,863
Location
Mn
Country flag
Received my 28'' Stihl light bar today. And I wanted to try my 3d printed adapter. I did some light cuts and I didn't notice anything bad, so I assume it would be safe to use.
But still I want to have one out of metal.

View attachment 363918 View attachment 363919

The Stihl 28'' light bar is almost one pound lighter than the Husqvarna 28'' regular bar.
Actually that adapter would probably be fine it’s more for alignment than anything, your clamping force of the cover to saw body should be doing 90% of the holding. I’ve seen lots of small machined tubes just dropped over bar studs for an adapter also.


GerbrandR

Super OPE Member
Local time
4:47 PM
User ID
17484
Joined
Jul 11, 2021
Messages
82
Reaction score
392
Location
The Netherlands <-> Austria
Country flag
Actually that adapter would probably be fine it’s more for alignment than anything, your clamping force of the cover to saw body should be doing 90% of the holding. I’ve seen lots of small machined tubes just dropped over bar studs for an adapter also.

That's what I figured too. Once the bar nuts are tight there is no movement. I think the possibillity of getting damaged is when sliding the bar on and off the adapter.


huskihl

Muh fingers look really big
GoldMember
Local time
10:47 AM
User ID
360
Joined
Dec 31, 2015
Messages
22,843
Reaction score
145,736
Location
East Jordan, MI
Country flag
Aftermarket ms660 hyway crankshaft shenanigans. Something didn't seem right when side x side with the oem one. Sure enough the keyway is machined 10° retarded from oem. The magnets in the aftermarket flywheel are 7° retarded from oem so if i did all my maths and figuring right, timing is 17° retarded total from factory. Atleast I know where I'm at timing wise now and can adjust. When it's all together and running, I may make some marks and hook a timing light up to see where things are exactly . Does anyone know what the factory spec for timing at idle is on these 660's by chance? I have the 1314 coil if it matters.
S=stock
H=hyway

View attachment 363649 View attachment 363650 View attachment 363651
Buy a PingLing coil and maybe you’ll get lucky and it’ll fire 17° early. 😁

Most late 0 and early MS Stihls run about 26-28° btdc with a flat curve


Agent Smith

Hack of all trades
Local time
10:47 AM
User ID
5180
Joined
Jan 28, 2018
Messages
3,088
Reaction score
18,331
Location
Northeast ohio
Country flag
Buy a PingLing coil and maybe you’ll get lucky and it’ll fire 17° early. 😁

Most late 0 and early MS Stihls run about 26-28° btdc with a flat curve
Lol I'm not that lucky. Believe me it pains me to have to run aftermarket stuffs but in this case I just couldn't afford oem. Probably be ok for as much as ill ever run it. I ended up advancing the flywheel a pinch over a full key width, applied some lapping grit to the crank and sinched it down. According to the timing light, I'm at 32° btdc now. Seems to run ok.

I did notice with the light hooked up at idle timing is retarded 10° and then right off idle it advances that 10°. Must be for ease of starting.


huskihl

Muh fingers look really big
GoldMember
Local time
10:47 AM
User ID
360
Joined
Dec 31, 2015
Messages
22,843
Reaction score
145,736
Location
East Jordan, MI
Country flag
Lol I'm not that lucky. Believe me it pains me to have to run aftermarket stuffs but in this case I just couldn't afford oem. Probably be ok for as much as ill ever run it. I ended up advancing the flywheel a pinch over a full key width, applied some lapping grit to the crank and sinched it down. According to the timing light, I'm at 32° btdc now. Seems to run ok.

I did notice with the light hooked up at idle timing is retarded 10° and then right off idle it advances that 10°. Must be for ease of starting.
Yeah that sounds good.

Wasn’t laughing at you, laughing with you. And at the f bombs coming from your shed. Adapt and overcome


JIMG

Pinnacle OPE Member
Yearly GoldMember
Local time
10:47 AM
User ID
18248
Joined
Aug 14, 2021
Messages
365
Reaction score
1,287
Location
NorthCountry
Country flag
Tinkering Sunday project.
Just parked my mastermind piston and cylinder in a spare parts assemblage until something more attractive comes along.


Attachments

  • milkcrate 1.jpg
    milkcrate 1.jpg
    148 KB · Views: 25
  • milkcrate 2.jpg
    milkcrate 2.jpg
    159.4 KB · Views: 18

Czed

Aluminium Member
GoldMember
Local time
10:47 AM
User ID
568
Joined
Jan 17, 2016
Messages
33,105
Reaction score
188,711
Location
Wv
Country flag
I rebuilt a couple of 272s one with a meteor piston kit one with a hyway popup kit
New carb kits,seals fuel lines etc.IMG_20230214_163147910.jpgIMG_20230214_164039594.jpgIMG_20230214_164058305.jpgIMG_20230214_175443998.jpgIMG_20230214_123334778_HDR.jpg
The meteor saw turned out great
Started and tuned easy
I cut with it all day
The hyway saws coil took a *s-word
I need to replace it before I cut with it.


Gullet

Here For The Long Haul!
Local time
9:47 AM
User ID
16836
Joined
Jun 17, 2021
Messages
2,483
Reaction score
12,701
Location
Arkansas
Country flag
Wished I would've used a condom when I filled the oil tank cuz it came all over my workbench... 😆
Get you one of those oil drip pans @ WM that goes under a vehicle to keep oil off driveway.
Offered in a few sizes, I have a big one I put on top of my workbench when working on, or filling saws.
Wipe off with paper towels & remove & I have my wood workbench back.


beaglebriar

The Peanut Gallery
GoldMember
Local time
10:47 AM
User ID
377
Joined
Jan 1, 2016
Messages
18,806
Reaction score
105,999
Location
Warren Center, PA
Country flag
Get you one of those oil drip pans @ WM that goes under a vehicle to keep oil off driveway.
Offered in a few sizes, I have a big one I put on top of my workbench when working on, or filling saws.
Wipe off with paper towels & remove & I have my wood workbench back.
I generally use PIG mat when working on/splitting a saw. This one had an unseen hole punched through the case from some jagoff using a long screw in the front handle. (I should have checked not the first time I've found this on a eBay saw) Not a big deal I can repair it easy enough...
