Echo Cs 730 hybrid build.

[Red97]

S'ok I hear that's how all the cool kids wear em these days... so thanks Echo. I guess...

Super surprised the cheap, brittle, sharp, junk, no good, ugly, flimsy echo plastiks didn't disintegrate in my hands!

Miracles do happen...

Sent from my SM-G950U using Tapatalk



[Red97]

Ran a couple tanks through at the gtg today. Swapped the carb,coil out as well. Seems to run a bit better with both.

Coil only had better throttle response and felt better in the cut.

Larger carb added a bit more in the cut without losing any throttle response or low end.

@Armbru84
@Canadian farm boy
@cus_deluxe
@huskihl
@Fifelaker
@EvilRoySlade

All had some trigger time on it today

Not quite the same league as ported 372, 044 hybrids or smurfy dolmar things... I think it has some potential to pick up a bit more.



[Armbru84]

Thanks Joe for letting us run it! I gotta say I was very impressed with it. The power and balance of the saw were sweet! You could lug it and it would still fling chips. Plus it sounded sweet!



[Red97]

Here is a video Armbru84 took after the carb/Coil swap.

Tuned around 13,800 14k is about the limit.



[Red97]

Think I have a plan...

Going to drop the jug .020

Should get my transfers down around 117.
Think they are open too long. Cant build enough pressure to force the remaining exhaust gasses out, especially with the low bd.

Then take the ex up to 99, for 18* bd widen as much as possible. Exhaust flange doesn't allow much more than 63%

Intake should end up around 77-78 probably widen the intake a bit too. Believe the small carb would benefit from the added area.

Seems this saw is running on (mass flow) not really building any "pressure".

Throttle response is good, but not near as snappy as Some, power delivery is very linear.

If I can get the transfers lower they will build more pressure. I believe I can get enough intake area to stuff the case better. With enough exhaust area to clear the chamber out. With such a narrow exhaust outlet I can see higher than normal ex numbers still making plenty of tq..

Only one way to find out it's just a jug



[Red97]

Just cause it fits the discussion.

@Jon1212

Sent from my SM-G950U using Tapatalk



[Armbru84]

Think I have a plan...

Going to drop the jug .020

Should get my transfers down around 117.
Think they are open too long. Cant build enough pressure to force the remaining exhaust gasses out, especially with the low bd.

Then take the ex up to 99, for 18* bd widen as much as possible. Exhaust flange doesn't allow much more than 63%

Intake should end up around 77-78 probably widen the intake a bit too. Believe the small carb would benefit from the added area.

Seems this saw is running on (mass flow) not really building any "pressure".

Throttle response is good, but not near as snappy as Some, power delivery is very linear.

If I can get the transfers lower they will build more pressure. I believe I can get enough intake area to stuff the case better. With enough exhaust area to clear the chamber out. With such a narrow exhaust outlet I can see higher than normal ex numbers still making plenty of tq..

Only one way to find out it's just a jug

I will be more than happy to come over and run it once ready [emoji16]



[Red97]

I will be more than happy to come over and run it once ready [emoji16]

Might have to grab brad and head up to you. Sounds like ya got quite the wood pile.

@Woodpecker

Sent from my SM-G950U using Tapatalk



[Woodpecker]

Might have to grab brad and head up to you. Sounds like ya got quite the wood pile.

@Woodpecker

Sent from my SM-G950U using Tapatalk

Looks like I may be headed over there on next Wednesday.



[tree monkey]

Think I have a plan...

Going to drop the jug .020

Should get my transfers down around 117.
Think they are open too long. Cant build enough pressure to force the remaining exhaust gasses out, especially with the low bd.

Then take the ex up to 99, for 18* bd widen as much as possible. Exhaust flange doesn't allow much more than 63%

Intake should end up around 77-78 probably widen the intake a bit too. Believe the small carb would benefit from the added area.

Seems this saw is running on (mass flow) not really building any "pressure".

Throttle response is good, but not near as snappy as Some, power delivery is very linear.

If I can get the transfers lower they will build more pressure. I believe I can get enough intake area to stuff the case better. With enough exhaust area to clear the chamber out. With such a narrow exhaust outlet I can see higher than normal ex numbers still making plenty of tq..

Only one way to find out it's just a jug

is it done yet?



[Red97]

is it done yet?

Almost. Hopefully try it tomorrow...

Got chained down today.

Sent from my SM-G950U using Tapatalk



[Red97]

Baseline before further mods. SOFT poplar...

Likely to be froze solid after I get the porting done lol

Sent from my SM-G950U using Tapatalk



[Red97]

Noodles. Someone asked how well the cover clears noodles.

Maybe it just can't make em fast enough,but seems to clear well.

Sent from my SM-G950U using Tapatalk



[Wood Doctor]

OK, that does it. I'm going to put a 28" bar on my my stock CS-670 and see if it can hold a candle to Red97's CS-730. Right now I have the 28" bar on my Stihl 046 Mag. That should prove interesting. Thing is, I don't have any soft poplar available -- only hard ash. So, to be fair, I may have to leave the 25" bar on there as is.



[Red97]

OK, that does it. I'm going to put a 28" bar on my my stock CS-670 and see if it can hold a candle to Red97's CS-730. Right now I have the 28" bar on my Stihl 046 Mag. That should prove interesting. Thing is, I don't have any soft poplar available -- only hard ash. So, to be fair, I may have to leave the 25" bar on there as is.

They run well once ported. Same jug just less stroke.

The 670's I have built will come up wanting against the 730.

Hopefully the 730 will get even stronger with some porting.

670's are a darn good firewood saw.

That was my goal while building this hybrid.

670 - 2lbs + 7cc + better av = cs730

What's not to like?



(Edit) that log is from the same tree, just a year younger.

Sent from my SM-G950U using Tapatalk



[bryanr2]

My experience with Echo is that they may not be as fast as a hopped up Husq but they are dead reliable. Id rather have the most dependable saw, rather than the fastest.



[heritageguy20051]

My experience with Echo is that they may not be as fast as a hopped up Husq but they are dead reliable. Id rather have the most dependable saw, rather than the fastest.

I'll second that! Also the easiest starting.

Sent from my E6782 using Tapatalk



[Armbru84]

They run well once ported. Same jug just less stroke.

The 670's I have built will come up wanting against the 730.

Hopefully the 730 will get even stronger with some porting.

670's are a darn good firewood saw.

That was my goal while building this hybrid.

670 - 2lbs + 7cc + better av = cs730

What's not to like?



(Edit) that log is from the same tree, just a year younger.

Sent from my SM-G950U using Tapatalk

I was gonna say Joe...it got a lot warmer looking from when I left this morning!!! Good running saw there too



[Red97]

My experience with Echo is that they may not be as fast as a hopped up Husq but they are dead reliable. Id rather have the most dependable saw, rather than the fastest.

I'll second that! Also the easiest starting.

Sent from my E6782 using Tapatalk

I agree, not quite the rpm. Tend to just tractor along..

But who doesn't like a fast tractor?

I was gonna say Joe...it got a lot warmer looking from when I left this morning!!! Good running saw there too

Think most of that was the wood got faster lol.



[Dub11]

I agree, not quite the rpm. Tend to just tractor along..

But who doesn't like a fast tractor?

I wonder if he was using a square ground plow?



Think most of that was the wood got faster lol.
