What's on your bench?

[TJ the Chainsaw Mechanic]

Waiting on new carbs for two BG55's. And in the middle of installing a good used tank housing on a hooksy 350.



[a. palmer jr.]

Got an 024 on my bench needing AV mounts, just got them in the mail today so it won't be long. Also an 028 needing a fuel line, still in the mail, probably later in the week I'll get 'er done. Also I own a Dolmar 5100S with a cat muffler on it, gonna try to find an early non-cat muffler for it, maybe perk it up a bit.



[backhoelover]

Anybody remember the initial carb setting for these some jackleg charged a guy for a full tuneup new lines filters kits etc. and did nothing but screw up the carbs they are in great shape otherwise.View attachment 64951 View attachment 64952

I'm pretty sure mine are both around 1 turn out


Sent from my iPhone using Tapatalk Pro

ding ding ding we have a winner



[tp2177]

Got the new carb on the tecumseh motor on that push behind weedeater. It runs great, but it's leaking oil around the full tube now. Gonna tear it back down tomorrow evening and see what that's about. I'm guessing it could use a new o ring. It is part of the housing that has to come off to get to the carb.


Sent from my iPhone using Tapatalk Pro



[stihl_head1982]

A MS390 that went "wonkie" as far as the tune is concerned. It HAD a Hutzl complete engine replacement. The PTO crank bearing crapped out after about 5 tanks.
I replaced the aftermarket crank with an OEM crank and some nice Nachi bearings. New seals and dirko on the pan and seals. Gonna test run it tomorrow.
Thankful that it is at least together.



[DND 9000]

@Czed

Tell us please what carburetor you have on your FS 80. (It`s written or stamped on the carb body) The basic setting with 1 and 1 on H and L is only valid for the Walbro WT-447 carburetor. But your machine looks like that it has a Zama carb on it. Trust me, I have the same machine with a Zama carb. On your shroud of the machine is the setting for the screws when the limiter caps are seated. But attention, this is only valid if the basic setting was done before the caps where installed, otherwise it is tuned to lean.



[Onan18]

Lazer 60 that the deck was out of kilter.



[X 66 stang347 X]

Customer stripped the rear bar stud in the engine sump on a ms310. Replacing sump and seals. [emoji17]



[X 66 stang347 X]

It's done and off to the next one. I have 8 saws, 12 trimmers, 10 blowers and 13 mowers so not much time to screw off today.



[Stackowood]

Replacing sump and seals.

Yuk



[TJ the Chainsaw Mechanic]

Got that 350 hooksy fixed up, runs perrty good. Now gonna start working on a pressure washer.



[X 66 stang347 X]

Yuk

I know right. That's 45 min Of my life I can't get back. Lol
Anyone want a free trimmer? Can see it needs a rope. It's a iconic FS44. Lol



[tp2177]

Got the oil leak figured out so the push behind weed eater is done waiting on parts to come in on the push behind edger. I am borrowing a pressure washer right now from a family member that hasn't had a lot of run time. What would make it to where you have to either hold the trigger down all the time to get full pressure out of it or have to drop the rpms pull the trigger and then bump the rpm back up to get full pressure while it's running. Once you let go and press it again the pressure is significantly less unless you drop the rpms and raise them again.


Sent from my iPhone using Tapatalk Pro



[dustinwilt68]

Working on my last 288xp I have, the piston top was ruined by a spark plug end coming off, luckily the cylinder was in good shape yet, installed a new oem piston, figured I would install a new fuel line and fitter as well. This saw has sat for quite some time, seems to be in very nice shape though.



[Czed]

Stihl bg55 and fs80 recently serviced by some jackass full kits line's etc which equates to a ngk plug lol
The bg55 has the new epa mud dauber exhaust filtration system the carb was loose on the fs80 don't know why he didn't even change the primer bulb's on either machine they's good to go now even pressure washed and heat painted the exhaust on both.



[67L36Driver]

Clinton D-35. Replaced the original Tilly HC with a 070/090 Tilly HL china clone.

Worked out an external impulse line by adding a tube spigot to the impulse passage in the carb.

Got it sort of running but a bit wonky.

Shouldn't the fuel supply line fill up while running?

Fuel tank plumb full.



[Tor R]

Cleaning cleaning and cleaning....Done with it at least on this saw.
Time to build her up...

Broke my seal puller and had to make a new one first


Easy to knock in seals with tools, that 242 PTO sleeve is worth every penny! The two tools to the right is to set correct deepht on Flywheel & PTO seal.


Shaved the key, as always. I do feel it give alot more attitude in 242 who isn't a slow saw normally.


More to come.........tomorrow.....maybe



[Czed]

A month hasn't went by that i haven't worked on one of this series lol



[X 66 stang347 X]

Waiting on new carbs for two BG55's. And in the middle of installing a good used tank housing on a hooksy 350.

Y'all run out? We go through those like candy. And the fs55's



[Stackowood]

192TC with a seal that popped out, kind of unusual. And a new Stihl ZAT4 spark tester.





Two more 192's waiting in line for a clean up and service. Some of the climbers frown on these, but with a few mods and the right tuning they can cut a lot of wood for 1/2 the price of a 201T.
