What's on your bench?

[dall]

you have him round filing ? or is he square filing yet



[Wolverine]

He came home (after 12 hours or so), put that saw in a vice and went to town with a Husky roller guide. Got one tooth kinda there, then came in for a shower and some eats. I was already in the garage so I filed away all the damage. He can touch it up if he wants in the a.m. He just hit the sack. Real work wears him out, lol! That's the worst chain I've ever saw.



[Wolverine]

He's doing pretty good with the guide.
(like this)



[huskyboy]



[Onan18]

Good gawd people!!!!!!!!!!
View attachment 74963 View attachment 74964 View attachment 74965
And it's bone dry to boot.

Meh, I have seen worse.



[Keith Gandy]

Here's a couple more pics of the house he builds.

Sent from my SM-G930V using Tapatalk

Freakin beautiful!!



[Keith Gandy]

Finished rebuilding the MS650. Shes ready for battle back in the tree service business



[rattler]

Nice 2004 359

Sent from my SM-G935V using Tapatalk



[bikemike]

Well I just ordered a new piston ring and crank seals for the old echo 360t 22 bucks after shipping. 6 years of 200 plus days a year use its still pulling strong but has a Lil blow by. If I had the cash I'd purchase a short block and port the old case. Kinda stoked to pull this old saw apart and freshen it up hopefully before the chainsaw races.



[TJ the Chainsaw Mechanic]

Fixed up an 044 today....rebuilt the whole fuel system and tuned up the saw. Runs pretty decent. It's a red lever 044 with the slant fins...10 mm???
Now working on two 362's with unknown problems.
Waiting on parts for a Shindawa t230x as well.



[MustangMike]

Go by the SN to determine if it is a 10 mm, but all the slant fins usually run real well.



[drf256]

Go by the SN to determine if it is a 10 mm, but all the slant fins usually run real well.

Or look at the top of the case extension on the starter side next to the muffler.

Curved = 10mm

Angled = 12mm

Square = 046



[drf256]

Two 44.7mm MS260 jugs. One for Rodney and one for a clean MS260 PRO I'll probably keep for myself.

Bases cut and plating chamfered. I'll cut the bands tonight.

So much for taking time off of saw work. A good buddy had an issue with his father's MS260 and I couldn't resist. I've got a soft spot for building someone's fathers saw.



[bikemike]

Two 44.7mm MS260 jugs. One for Rodney and one for a clean MS260 PRO I'll probably keep for myself.

Bases cut and plating chamfered. I'll cut the bands tonight.

So much for taking time off of saw work. A good buddy had an issue with his father's MS260 and I couldn't resist. I've got a soft spot for building someone's fathers saw.

View attachment 75083 View attachment 75085 View attachment 75086 View attachment 75087

What you charge to cut squish and base on a 026 pro? I may be intrested in a compression bump.



[T.Roller]



[drf256]

What you charge to cut squish and base on a 026 pro? I may be intrested in a compression bump.

If you want it to run well, you need port work after dropping the jug.

Cutting the stock band out, sanding the chamber to match the piston, and cutting the base (to yield .020 squish) on a 44mm 026 jug will yield

100/132/73



[bikemike]

If you want it to run well, you need port work after dropping the jug.

Cutting the stock band out, sanding the chamber to match the piston, and cutting the base (to yield .020 squish) on a 44mm 026 jug will yield

100/132/73

Porting has been played with and as a oh26 fanatic you are I'm shure you would love how this saw runs. I'd be willing to bump my transfer port back up a bit if needed but this Lil *b-word runs. Only catch is im a base gasket guy. I know they can be sealed up good without a gasket but I like to have a base gasket to help keep harmonic vibes down and a stupid sense that a gasket can help keep a case and bearings cooler than metal to metal



[Sawrain]

E46 bmw's, they all rip the subframe mounts out of the carrier panel! Kind of my bench.



[Keith Gandy]

Started 660 this morning. Needed a piston/ring, intake boot, tank, new controls and wiring harness. Cylinder cleaned up well Pressure ck showed good. Must have straight gassed her



[MustangMike]

Keith, where did you get (what is it):

1) to block the intake,

2) to provide air through the plug?

Also, I use a 034 muffler spacer with a double layer of bike inner tube, and some short bolts, to seal the exhaust. It is a lot easier to work with (instead of re-installing the whole muffler.
