I'm getting trained to analyze diesel engines as part of my job. I really wish the equipment would work on high speed engines like chainsaws but it's for slow speed diesel engines and reciprocating compressors.
Here's and example of the data that's collected.
X axis is crank angle where 0 is TDC.
The blue line is the cylinder pressure. The squiggly lines are all vibration data picking up signatures from intake and exhaust opening. You can diagnose valve train noise, injector issues and other mechanical issues within the engine.
