Post up your ported cylinder Artwork

[Lightning Performance]

Stock intake pics, and the cylinder needed the screw pockets clearanced as well as the corner of a fin before it would mount on the saw. I like how the exhaust is lower than OEM, and the squish was huge, so I could just cut the base, keep the gasket, and end up around 105.

View attachment 258127 View attachment 258128

I also improved the gap between the fins.
View attachment 258126

That is a pretty horrendous intake port and tongue.



[huskihl]



[Canadian farm boy]

Jonsered 2171



[Nutball]

Squared piston



[ChipsFlyin]

East Coast porting!



[PA Dan]

East Coast porting!
View attachment 259838

Nice artwork Mark! I like the attention to detail and the gentle shading! The black and white adds to it! Final thought though...don't quit your day job!



[Nutball]

Now lets see that exhaust port opened up!



[PA Dan]

Now lets see that exhaust port opened up!

Whats up with the squared piston?



[Nutball]

I tried to match the curve of the exhaust roof on the piston crown for full width opening all at once.



[PA Dan]

I tried to match the curve of the exhaust roof on the piston crown for full width opening all at once.

How did it work out?



[Nutball]

I'll find out this weekend or next. I did it to my JD 56, but didn't do a before and after of that mod alone, so I don't know what the gains are.



[Nutball]



[Ronie]

372 I'm putting together.



[redlight066]

MS461 Stock with gasket was 70/121/106, ended up at 81/119/101. This was in for repairs and performance work. I’ll head out in the morning and do some testing. We’ll see how it runs, I may go a little further with it. Going to be a work/play saw.



[redlight066]

Thanks @Duke Thieroff for the rear handle/tank. Housing went back on the saw with all of the OEM linkages, fuel vent and line. Tank held pressure with no leaks. Yay!! Saved Almost $100 over one at the parts counter.



[Maintenance Chief]

Im loving this thread , and learning alot about port work....
But seriously my hands look like dog paws that have been through greasy machines, compared to the hands I see on here!
I'm starting to think porting is definitely a art form for skilled craftsmen.



[Maintenance Chief]

I can do the honing with my palm if that counts.



[smokey7]

When you work full time on diesels black hands is permanent.



[Deets066]

You guys need some ZEP cherry bomb and a scrub brush.



[ranchdadmike]

You guys need some ZEP cherry bomb and a scrub brush.

Or this (at 32:1):
