Prototype is not a problem... Shaun (or someone that can tig weld aluminum) could weld a pop-up on a piston and then run it on the lathe to clean it up and cut it down to the right size. 290-390 would be an easy one to fit test since they are a clam shell and easy to bolt up to test clearance. There are 4 bore sizes you would have to make to fit all the farm boss series.I've been thinking of doing something like that. Piston are relatively inexpensive to copy. 029 and 039 would be the first I would make. Is the combustion chamber the same on all of the 029 and 039's?
We need someone to make a prototype.
Yea i know... that's the minimum I would like to see come from an AM crank. I have seen them blow out in under 20-30hrs of use!200 hrs isn't much that's not for off from the epa tag on poulans and homelite Homeowner saws
I'd do the 46mm and 49mm. But 49mm first. So what do you need from me to get it done?Prototype is not a problem... Shaun (or someone that can tig weld aluminum) could weld a pop-up on a piston and then run it on the lathe to clean it up and cut it down to the right size. 290-390 would be an easy one to fit test since they are a clam shell and easy to bolt up to test clearance. There are 4 bore sizes you would have to make to fit all the farm boss series.
45mm - 029
46mm - 029 super, 290
47mm - 310
49mm - 039, 390
Maybe have someone port a cylinder kit we like and then make a piston to fit and have both copied...??? Or just have a piston cut for a cylinder you have on the shelf (like a Cross Performance). It would be easier to control the quality if the high performance piston was sold exclusively for a certain cylinder or in cylinder kit. I can just imagine someone blowing apart their saw with a domed piston because they didn't check clearance. I would start with the 49mm size first since its almost the same price for more displacement. Last thing that comes to mind is that I would not do this option for saws that commonly have crank problems... just my 2 cents...
I have at least a dozen OEM and AM cylinders sitting around to look at the chamber shape if needed. might be able to have shaun mach up a piston over the holidays since I have a 084 crankcase for him to weld anyhow...
You get a 365/372 crank? How do they look? I need to make another order soon for a couple 372 builds...I ordered on the same deal and also received made in China pistons. I ordered a couple of the cranks as well. They showed up in boxes marked Precision Tooling which is an Italy based company but there are no marks of any kind stating country of origin on the boxes.
Which cylinder kit do we like the most? I have been partial to the Cross Performance kits with cabers since I have had issues with the cheaper rings loosing compression on me after a couple heat cycles. I'd think that would be a good jumping off point...? Let me text shaun and see what he needs and if he would be willing to mach one up for us. I usually have to bribe him with cash or chainsaw parts to do machine work for me... Maybe a good bottle of something will work...I'd do the 46mm and 49mm. But 49mm first. So what do you need from me to get it done?
Is there an aftermarket one? I'll look for it.are we going to see any AM 372xp air filter covers in the near future?
We could make a sample but it might not happen for a while. What could we do to it?Also do we want to mess with cylinder port timing at this point or not?
Let me know what you need or I can pay him.I usually have to bribe him with cash or chainsaw parts to do machine work for me
You get a 365/372 crank? How do they look? I need to make another order soon for a couple 372 builds...
Is there an aftermarket one? I'll look for it.
We could make a sample but it might not happen for a while. What could we do to it?
The pistons are more important. We just need to make sure it will work in the OEM and aftermarket cylinders.
Let me know what you need or I can pay him.
Does anyone have an OEM cylinder and piston for sale? I can always order one here.
Send me the shipping address. I will also send you our cheaper 039 cylinder. Just to see if the piston can fit as well.I need:
1.) cross performance 49mm cylinder kit
2.) spare cross 49mm piston. I'll do compression readings back to back with stock vs pop-up on both OEM and Cross cylinders.
I have a 49mm oem topend that I ported too wide on the transfers we could use it for a test on a piston with a popup. I have an oem
The numbers on the ms 390 were very good you can't widen the transfers or you will hook a ring unless we had the ring ends moved like what is on a 372xt
I think the pistons need to be 10 thou taller and a small popup like a quarter ($0.25) with a bevel
let me know if I can help in this process at all
what are you thinking Shaun? Like a 026, 028S or like the wiseco 372 pistons?I'll probably make the pop up domed.
I think the pistons need to be 10 thou taller
