Searching for Es Light bar weights

[leadfarmer]

The bar only. Then I can make an apples to apples comparison. Thanks

I'll see if I can remember tomorrow



[Backtroller]

When I inquired about a 24” rollomatic e, not es, It was not available anymore. I remember seeing them years ago.



[leadfarmer]

Here u go buddy



[Backtroller]

Thank you! I appreciate it. That is light.



[jk14]

I have been trying to find a real world weight of a Stihl es light 25” 3003 000 2231. 3/8 .050 84 bar. I have found 20” and 32” but I can’t find other weights. Anyone have a source?

I posted weights of 20,25,28 and 32 es-light weights on here somewhere around January 2017 but I can not find it. The search doesn't work worth a *s-word. Maybe you'll have better luck. I will be out in the shop later this afternoon and will weigh them again.



[jk14]

The bar only. Then I can make an apples to apples comparison. Thanks

Oh wait I found it.

http://opeforum.com/posts/312061/

20" e standard .325-.063 = 2lb. 6.3oz
20" ES light 3/8-.050 =2lb. 0.9oz.
25" ES =3lb. 10.7oz.
25" ES light =2lb. 9.6oz.
28" ES =3lb. 14.2oz
28" ES wide nose. =4lb. 1.7oz.
28" ES light. =2lb. 12.0oz.
32" ES light. =3lb. 5.2 oz.



[00wyk]

Thanks, I had found that and while he had the es light weights for the 20” 28” 32” and 36,” there is not any 24-25” es lights. Just standard ES in that 24-25 length.

Guide bars: Rollomatic ES Light, 3/8", 1,6 mm, 63 cm / 25"
30030002031 VS 2038 for the 28" bar.
30030002021 for the 20" light.

Whether you can get them stateside is another matter.



[Backtroller]

We have no problems getting the bars. They are pretty abundant, if you want to pay the price. I was inquiring about their weights.



[Duane(Pa)]

You said Abundant! Good word...



[Backtroller]

Mike Tyson word of the day dictionary.



[Slacker]

Dear Stihl:
Please make a 18" ES light 3/8 .050.
It's what I want for my birthday.



[Matt Ellerbee]

Dear Stihl:
Please make a 18" ES light 3/8 .050.
It's what I want for my birthday.

Tsumura makes one, if it helps.



[Slacker]

Tsumura makes one, if it helps.

I PM'd, texted and sent bat signals to our resident Tsumara seller asking about buying a 16". No response.

It is Tsumara PN 200FK4.
D025, 3/8, .50 for the 16"

The same in 18" is PN 201FK4



[Matt Ellerbee]

I PM'd, texted and sent bat signals to our resident Tsumara seller asking about buying a 16". No response.

It is Tsumara PN 200FK4.
D025, 3/8, .50 for the 16"

The same in 18" is PN 201FK4

Correct. But the 16” is not light weight, the 18” is.



[Redbull661]

- 24" tsumura redesigned 050 3/8 84dl = 2lbs 7 oz (so it dropped some weight)

- 24/25" Stihl es light 063 3/8 84dl = 2lbs 8.5oz

not exact apples to apples but I would guess

- 24" tsumura 063 would be approx 1-2oz more (because tsumura uses thicker bar on the 063s)

- 24/25" stihl in 050 would be approx 1oz more @ 2lbs 9.5 oz. (because stihl uses the same thickness bar on 063 or 050...so with 050 there would be more metal left in the bar)

-------------------------------------------------------------------------------------
at least on all the Tsumura husky and stihl mounts I sell. FV = regular weight bar. FK = light weight.

I had my distributor order 16 + 18" lights 050 3/8 stihl mt (200FK4, 201FK4 ) back in Nov. ..should be here sometime in may. Also
237FK4 32" 063 stihl light,
238FK4 36" 063 light,
244FK4 32" 050 3/8 light,

433FK4 husky .063 32" light,
434FK4 husky 063 36" light



[Slacker]

at least on all the husky and stihl mounts I sell. FV = regular weight bar. FK = light weight.

I had my distributor order 16 + 18" lights 050 3/8 stihl mt (200FK4, 201FK4 ) back in Nov. ..should be here sometime in may. Also
237FK4 32" 063 stihl light,
238FK4 36" 063 light,
244FK4 32" 050 3/8 light,

433FK4 husky .063 32" light,
434FK4 husky 063 36" light

Please PM me when they show.
I'm in for a 3/8 .050 18" ES light.



[PA Dan]

I mainly wanted to compare a Tsumura light to the Stihl ES light. I was curious how much difference there was between the two. The Tsumura is so much cheaper.

And it looks better!



[Backtroller]

I’ll have both of them to compare in a week or so. However, I can’t really see my wood pile currently with all of the snow.
