Next up, round 2-288xp rebuild

[roadster27]

Early KS (kolbenschmidt) non decomp 288 cylinder.

Use the mastermind method to sand the transfer off with a split mandrel and aluminum oxide emery cloth.

Thanks. I think I have seen that before in a video somewhere... I'll try it. And see how she cleans up.



[00wyk]

That's what I'm talkin about....! Lol
But I'm 35, 6'2", 230 lbs, and young and dumb.... lol

I tried to take a reading today. I failed. I pulled it over twice and then went to lunch. I meant to swap the jugs and piston today but I just ran out of time.



[roadster27]

I think I may be going all the way on one of these saws now.... who does powder coating. I've heard @Glock37 is the the guy for it.



[p61 western]

I think I may be going all the way on one of these saws now.... who does powder coating. I've heard @Glock37 is the the guy for it.

That's the right guy, and he does a great job.



[00wyk]

The cylinder had had some grinding done....
View attachment 148951 View attachment 148952 View attachment 148953 Also we now know how it became a parts saw...
View attachment 148954 View attachment 148955 I will see if the aluminum transfer will clean off the plating. Is there any special tricks for this. I don't really want to do the acid....

That things needs to call a domestic violence counseling center. It must scream, tho.



[00wyk]

That's what I'm talkin about....! Lol
But I'm 35, 6'2", 230 lbs, and young and dumb.... lol

You might be young, but a new recoil assembly is gonna cost you the same This is on it's second in 3 years.
I am still waiting on the local dealer to get the needle bearings in. I didn't want to do this swap with both the old ones in. Was supposed to be today

I'm falling behind...



[roadster27]

Well I'm back to the pair of 288's. I got the transfer off off the plating in the second saw, but think I got a little to happy with the Emory cloth around the ports. Think I should have started with a more aggressive grit, would have worked fast and I wouldn't have "sat" as long around the port..... oh well. This cylinder was a long shot to start with. I'm not a big fan of the last guys idea of a port job.
What do you guys think if I run it? How do you think the plating will hold up? I don't care about the cylinder, but it needs new piston. I don't want to spend a bunch of money on this top end but would like to see it run and maybe learn a few things about the last porters ideas of what it should be. Not sure if I want to buy a meteor just to have it ruined in the bore. Or end up having a bad cylinder from the start as new cylinder already come with pistons.....
If anyone had an ok use piston for cheap I might be interested.
Before:
After:what do you guys think if i run it with the plating like that. I don't care about the life to much....



[Canadian farm boy]

Well I'm back to the pair of 288's. I got the transfer off off the plating in the second saw, but think I got a little to happy with the Emory cloth around the ports. Think I should have started with a more aggressive grit, would have worked fast and I wouldn't have "sat" as long around the port..... oh well. This cylinder was a long shot to start with. I'm not a big fan of the last guys idea of a port job.
What do you guys think if I run it? How do you think the plating will hold up? I don't care about the cylinder, but it needs new piston. I don't want to spend a bunch of money on this top end but would like to see it run and maybe learn a few things about the last porters ideas of what it should be. Not sure if I want to buy a meteor just to have it ruined in the bore. Or end up having a bad cylinder from the start as new cylinder already come with pistons.....
If anyone had an ok use piston for cheap I might be interested.
Before:
View attachment 151491 After:View attachment 151492what do you guys think if i run it with the plating like that. I don't care about the life to much....

From the pictures, I'd run it on my own saw. I don't think it would hurt anything. Meteor pistons aren't to expensive if you do have a problem.



[XP_Slinger]

From the pictures, I'd run it on my own saw. I don't think it would hurt anything. Meteor pistons aren't to expensive if you do have a problem.

+1 for running it.



[Fruecrue]

Run it.



[roadster27]

I know this is a question often asked and covered, most of you have your own way that works well for removing flywheels. However This question always seams to resurface. So I made a video on how I remove my flywheels.

I built these knockers on my lathe and cover the details in this thread on the first page. They say a picture is worth a thousand words so a video must be worth 2 thousand...

At the 38 sec mark you can hear the difference when it pops free.



[XP_Slinger]

Well I'm back to the pair of 288's. I got the transfer off off the plating in the second saw, but think I got a little to happy with the Emory cloth around the ports. Think I should have started with a more aggressive grit, would have worked fast and I wouldn't have "sat" as long around the port..... oh well. This cylinder was a long shot to start with. I'm not a big fan of the last guys idea of a port job.
What do you guys think if I run it? How do you think the plating will hold up? I don't care about the cylinder, but it needs new piston. I don't want to spend a bunch of money on this top end but would like to see it run and maybe learn a few things about the last porters ideas of what it should be. Not sure if I want to buy a meteor just to have it ruined in the bore. Or end up having a bad cylinder from the start as new cylinder already come with pistons.....
If anyone had an ok use piston for cheap I might be interested.
Before:
View attachment 151491 After:View attachment 151492what do you guys think if i run it with the plating like that. I don't care about the life to much....

Somebody did a nice job opening them lowers to mimick a Jonsered 930.



[qurotro]

These 288 are tough saws. I clean out half pound of oil soaked sawdust from mine. Put a new hyway kit in it and base gasket deleted. She sings.
The original P&C was so worn that the piston is 0.2mm smaller than the bore. But crank and bearing seems fine.



[XP_Slinger]

These 288 are tough saws. I clean out half pound of oil soaked sawdust from mine. Put a new hyway kit in it and base gasket deleted. She sings.
The original P&C was so worn that the piston is 0.2mm smaller than the bore. But crank and bearing seems fine.

Yes sir they are definitely tough. Same crank is used in 394/395, bullet proof bottom end for the smaller 54mm bore of the 288. Great saw.



[danimal]

Yes sir they are definitely tough. Same crank is used in 394/395, bullet proof bottom end for the smaller 54mm bore of the 288. Great saw.

That bottom end is bulletproof @56mm bore, IF taken care of. And limit 4ft bar use.



[00wyk]

I got the 288 back together. All I did was give it some more intake timing and width, but nothing crazy. And I opened up the bottom transfers maybe 4mm to get rid of the lip mainly. I want a mostly stock running saw. And it did have that great stock idle we're used to hearing, but a much better throttle response. It did... the wiring is messed up. So got to repair that. I'm away from the estate for a bit here, so shes still sitting

Anyone got a wiring diagram so I don't mess it up since I prolly won't see her for a month, and god knows who is gonna mess with it when I am away...?



[XP_Slinger]

I got the 288 back together. All I did was give it some more intake timing and width, but nothing crazy. And I opened up the bottom transfers maybe 4mm to get rid of the lip mainly. I want a mostly stock running saw. And it did have that great stock idle we're used to hearing, but a much better throttle response. It did... the wiring is messed up. So got to repair that. I'm away from the estate for a bit here, so shes still sitting

Anyone got a wiring diagram so I don't mess it up since I prolly won't see her for a month, and god knows who is gonna mess with it when I am away...?

Blue wire to kill switch, red wire to secondary coil in carb box

Edited to correct wire color to coil



[danimal]

Yep.



[roadster27]

Hi everyone. Sorry to dig up an old thread but I’m FINALLY back on rebuilding These pair of 288’s. Last post from me looks like a year and a half ago. The saws hasn’t move from the bench the whole time. I just worked on my other projects around them. Its been to long and I would like my bench back lol.



[TreeLife]

Hi everyone. Sorry to dig up an old thread but I’m FINALLY back on rebuilding These pair of 288’s. Last post from me looks like a year and a half ago. View attachment 241327The saws hasn’t move from the bench the whole time. I just worked on my other projects around them. Its been to long and I would like my bench back lol.

You might think it took a while to update, but it wasn't. Lots of guys living in the real world dont have all the time available to them. I'm at the same point with a very special 024 that was given to me.
